GMT High Speed Pipe Cutting Machine Model GPL-6020

GPL 6020 is a high speed intelligent laser machine for processing metal tubes.
Maximum Tube Length of 6000 mm, Dia : 20-220mm with laser power of 500-6000W can be provided.
Easy feeding, High Speed tube change.

Category: gmt laser

NO.		ITEM	GPL-6020
1	CHUCK	Type	Mechanical Self-centering Chuck and Pneumatic Chuck
		Diameter (mm)	Ø 20- Ø 220
		Min. Waste Length ( mm)	190
		Rated Resolution ( r/min)	40
		Max. Resolution ( r/min)	80
		Weight Bearable ( Together)	150Kg
2	X AXIS	Travel (mm)	6800
		Travelling Rated Speed (m/min)	43
		Travelling Max. Speed (m/min)	86
3	Y AXIS	Travel (mm)	400
		Travelling Rated Speed (m/min)	40
		Travelling Max. Speed (m/min)	60
4	Z AXIS	Travel (mm)	180
		Travelling Rated Speed (m/min)	30
		Travelling Max. Speed (m/min)	60
5		Positioning Accuracy	±0.05/1000mm
6		Repeat Positioning Accuracy	±0.05

Check out the technical data sheet and machine details in our brochure
